- Possible 10,000 r.p.m. highest speed chuck.
- Model HN chucks are assembled with adaptor for ASA B5.9 type A spindles.
- Model HN chucks are manufactured form high grade alloy steel. All sliding surfaces are hardened and ground for accurate actual running
- and long service repeatability.
Thank you for visiting our website. Your personal privacy is absolutely respected and protected by the website. To help you understand how the website collects, uses and protects your personal information, be sure to read the websitePrivacy Policy. Thank you!
HN
3-jaw extra high speed through-hole power chuck (adapter included)
Drawings
Specifications
| SPEC Model | Through -Hole (mm) | Plunger Stroke (mm) | Jaw Stroke (In Dia.) (mm) | Max. Pull Force kN(kgf) | Max. Gripping Force kN(kgf) | Max. Operating Pressure MPa(kgf/cm2) | Max. Speed (r.p.m.) | Weight (kg) | Moment Of Inertia I (kg‧m2 ) | Matching Cylinder | Matching Soft Jaw | Gripping O.D. Range |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HN-06 | Ø36 | 12 | 5.5 | 30(3050) | 79.4(8100) | 2.9(30) | 10000 | 11.5 | 0.035 | HG-1336 | Model-A | Ø14-Ø51 |
