- All sliding surfaces are hardened and ground for accurate actual running and long service repeatability.
- Mounting : Adaptor mounting to fit with DIN, ISO, BS, ASA, B5-9 type A spindles.
Thank you for visiting our website. Your personal privacy is absolutely respected and protected by the website. To help you understand how the website collects, uses and protects your personal information, be sure to read the websitePrivacy Policy. Thank you!
F66
High speed and light weight type strong finger chuck for aluminum wheel
Drawings
Specifications
| SPEC Model | Applicable Wheel Size | Out Dai. Of Chuck (mm) | Available Spindle Nose | Max. Pull Force (kgf) | Max. Gripping Force (kn) | Max. Operating Pressure MPa(kgf/cm2) | Max. Speed (r.p.m.) | Weight (Without Jigs) (kg) | Matching Cylinder |
|---|---|---|---|---|---|---|---|---|---|
| F66A8 | 19"-24" | 660 | A2-8 | 3000 | 3300 | 2.9(29.5) | 1500 | 182 | MS125C35 |
